STM Sinewave Inverter Drive Module (Grid Sharing) + CT

The STM Sinewave Inverter Drive Module with Grid Sharing Functionality and an included Current Transformer (CT) delivers powerful and efficient inverter control. First, it drives high-efficiency inverters with precision and stability. Next, it intelligently balances power between your solar system and the utility grid using advanced load-sharing techniques.

Then, it detects real-time load conditions through CT sensing for accurate performance. After that, it generates a smooth and stable sinewave output for reliable power delivery. Moreover, it fits perfectly into hybrid inverter systems that require smart energy management. Finally, it boosts overall efficiency while ensuring consistent and optimized power flow.

Key Features

• First, use Grid Sharing to seamlessly switch between solar and grid power.
• Next, enjoy a smooth and stable pure sinewave output for sensitive devices.
• Then, monitor loads accurately with the included CT (Current Transformer).
• After that, connect easily with 12V, 24V, or 48V battery banks.
• Also, control operations smartly with the microcontroller-based STM drive system.
• Moreover, reduce power loss with high efficiency and low Total Harmonic Distortion (THD).
• Finally, use it with confidence for custom UPS and solar inverter setups.

Applications

• Solar Inverter Systems
• Smart Grid Sharing Setups
• DIY UPS Projects
• Off-grid and Hybrid Energy Systems

Related Product

• STM Sinewave Inverter Drive Module Pin to pin
• Nand Gates Ic 74hc00 Nand Ic 7400 74ls00
• Stepper Motor Driver Stk672-050

Learn More

• True sine inverter circuit - does not produce a sine wave - why?
• Generating a sine wave using STM32G4
• Seeking Efficient Method for Generating Sine Wave

FAQs

Q1: What is the function of the CT included in the package?

A: The Current Transformer monitors real-time load and helps the module determine when to switch between solar and grid power sources.

Q2: Can I use this module with a 48V solar inverter?

A: Yes, it is compatible with 12V, 24V, and 48V systems depending on your setup and transformer specifications.

Q3: Does this module include a display or LCD?

A: No, the base module does not include a display, but one can be added depending on your custom inverter design.

Q4: Is this module programmable?

A: It uses an STM controller and is pre-programmed. Custom firmware may require development knowledge and tools.

Package Includes

• 1 × STM Sinewave Inverter Drive Module (Grid Sharing)
• 1 × Current Transformer (CT)
