The 1N5408 Power Diode! Designed for demanding applications, this rectifier delivers efficient AC to DC conversion. With a 1000V voltage rating and 3A current handling capacity, it's ideal for power supplies, inverters, and also motor drives. Although trust in the 1N5408 for reliable performance in your high-power circuits. Buy now to enhance your power electronics projects!

1N5408 Power Rectifier Diode is an axial leaded general-purpose rectifier in the DO-201AD package. The device features a diffused junction, high current capability low forward voltage and also low reverse leakage current. In addition Maximum repetitive reverse voltage Vrrm of 1kV.  Moreover non-repetitive forward surge current IFSM of 200A.

Specifiication and features of 1N5408 Power Diode :

• small size
• It has a maximum capacity of surge current
• A low forward drop of voltage
• Accessible within volume quantity
• Forward current (Avg) is 3A
• A forward drop of voltage is 1V at 3A
• Max non-repetitive current is 200A
• Max reverse current is 10uA.
• Cyclic reverse voltage is 1000V
• Accessible within DO-201 Package
• Rectifier Diode type used in general purpose applications
• Reverse current max is 10uA
• Non-repetitive fwd current max is 200A
• Max operating & storage temperature ranges from -65 Centigrade to +175 Centigrade

Pin cofiguration:

• Pin1 (Anode): This terminal is used to allow the flow of current
• Pin2 (Cathode): The flow of current will be exit through this terminal

Package Includes:

• 1 x 1N5408 Power Diode In Pakistan
