CD4016 Quad Bilateral Analog Switch IC - two black 14-pin dual in-line package integrated circuits on a white background.
CD4016 Quad Bilateral Analog Switch IC
Sale priceRs 100

The CD4016 is a quad bilateral switch intended for the transmission or multiplexing of analog or digital signals

Specifications:

  • VDD Supply Voltage:  −0.5V to +18V
  • VIN Input Voltage:  −0.5V to VDD + 0.5V
  • TS Storage Temperature Range: −65°C to + 150°C
  • Power Dissipation (PD): Dual-In-Line: 700 mW
  • Lead Temperature: 260°C

Applications:

  • Analog signal switching/multiplexing
    Signal gating
    Squelch control
    Chopper
    Modulator/Demodulator
    Commutating switch
  • Digital signal switching/multiplexing
  • CMOS logic implementation
  • Analog-to-digital/digital-to-analog conversion
  • Digital control of frequency, impedance, phase, and analog-signal gain

Cd4016 Quad Bilateral Analog Switch Ic CD4016 IC Datasheet
