9 Pin 2.5mm Jst Xh Style Pcb Mount Male Connector
9 Pin 2.5mm Jst Xh Style Pcb Mount Male Connector

9 Pin 2.5mm Jst Xh Style Pcb Mount Male Connector

Rs 14 PKR
SKU: B835,L20,Th10
Availability: In Stock In Stock Out of stock
Add to Wishlist
Description

These shrouded, 9-pin JST XH-style male connectors have straight leads and match the female connector on the 9-pin female XH-style cable, and they also work with other many other 0.1″-pitch female connectors, such as our female premium jumper wires. They are sold in packs of four units.

The B2B-XH-A(LF)(SN) is a part of XH series with a mounting height of 9.8 mm and it is applicable to PC Board thickness of 1.6 mm. It has an Operating Temperature range of -25° C to +85° C.

Product Features:

  • Original folded beam contact
  • Box-shaped shrouded header
  • Header with a boss
  • Interchangeability
  • Conforming to the HA terminal
  • Current Rating: 3A AC, DC(AWG #22)
  • Voltage Rating: 250V AC, DC
  • Contact Resistance: Initial value/10mΩ max.
  • Insulation Resistance: 1000 MΩ min
  • Withstanding voltage: 1000V AC/minute
  • Applicable wire: AWG #30 to #22

Best online shopping website for 9 Pin 2.5mm JST XH Style PCB Mount Male Connector in a cheap price in Lahore, Islamabad, Karachi, Faislabad, Multan, Quetta, Sukkur, Peshawar, Rawalpindi and all over Pakistan.
