Name: 12V 24V 10A Solar Charge Controller Dy-002
Brand: Digilog Electronics
SKU: B505,krt155,krt150,TMD5,Th2,
Price: 910.0 PKR
Availability: InStock

Home Solar & Inverter

12V 24V 10A Solar Charge Controller Dy-002 - a blue and black rectangular device with a central LCD screen, three buttons, dual USB ports, and terminals.

12V 24V 10A Solar Charge Controller Dy-002 - a black and blue controller with a digital screen, three buttons, two USB ports, and a settings diagram.

12V 24V 10A Solar Charge Controller Dy-002 - a black rectangular device with a blue front panel, LCD screen, three buttons, and two USB ports.

12V 24V 10A Solar Charge Controller Dy-002 - connections for a solar panel, battery, inverter, light, fan, and washing machine.

12V 24V 10A Solar Charge Controller Dy-002 - a blue and black controller with a screen, three buttons, and two USB ports, surrounded by solar panel scenes.

12V 24V 10A Solar Charge Controller Dy-002 - shown from front and top angles with dimension labels, an LCD screen, three buttons, and two USB ports.

12V 24V 10A Solar Charge Controller Dy-002

Rs 910

SKU: B505,krt155,krt150,TMD5,Th2,

Pickup available at Digilog Electronics

Usually ready in 2 hours

12V 24V 10A Solar Charge Controller Dy-002

Rs 910

The Dy-002 Solar Charge Controller can automatically manage the working of solar panels and batteries in a solar system. A solar charge controller is used for protecting the lifespan of your battery, but once the voltage of the battery drop below 8V, the solar controller will turn off automatically (LCD will be unavailable at the same time).

Dual USB Port Of Solar charge controller:

The solar charge controller with dual USB ports:

USB Output: 5V/2A max. 12V/24V auto
Rated Charge & Discharge Current: 10A
Settable operating modes of loads
fully 4-stage PWM charge management.

Solar Battery:

Solar Charge controller is only suitable for lead-acid batteries: OPEN, AGM, GEL, not for nickel hydride, lithium, Li-ions, or other batteries. For protecting the lifespan of your battery, once the voltage of the battery drop below 8V, the solar controller will turn off automatically

Multiple Electric Protection of Solar Charge Controller:

Short-circuit protection,open-circuit protection, reverse protection, overload protection, more safety for using, suitable for home, industrial, commercial etc.

Easy to Install and Operate Solar Charge Controller:

Hence Solar controller can clearly indicate the status and data, it can be conveniently switched modes and parameter configuration.

Good Heat Dissipation:

Dual mosfet reverse current protection, low heat production(ALL electronic components generate heat when they are running, it is better to shelter them for better heat dissipation, avoid direct sunlight exposure or damp place)

Easy to Operate and Installation:

Wiring STEPS: Screw the adjustment screw counter-clockwise until the plates move down. Insert the wire into the new opening between the plate and the "top" of the Terminal hole, not under it. Moreover Screw the adjuster clockwise and the plate will move upwards thereby squishing the wire

in the Terminal hole.

Installation STEPS：Connect the system in the order of 1.Battery > 2. Load > 3.PV Array in accordance with Figure, and disconnect the system in the reverse order 3. 2 .1.
