TheΒ IRF9540 P-Channel Power MOSFETΒ is a high-performance Hexfet Power Mosfet now available in Pakistan at Digilog.pk.Β This advanced MOSFET technology has been especially tailored to reduce on-state resistance and provide superior switching performance and high avalanche energy strength12.
Key Features:
- P-Channel Power MOSFET:Β The IRF9540 is a P-channel MOSFET that can drive maximum load current up to -19A and voltage up to -100V2.
- High-Speed Switching:Β Designed for fast-switching applications, the IRF9540 offers high-speed switching2.
- Low Turn-On Resistance:Β The IRF9540 is designed to have low on-state resistance2.
- Repetitive Avalanche Rated:Β The IRF9540 is repetitive avalanche rated2.
- Ease of Paralleling:Β The IRF9540 offers ease of paralleling2.
Technical Specifications:
- Drain-to-source voltage VDS: -100 V2
- Maximum Continuous drain current ID: -19 A2
- Maximum Pulse drain current: -72 A2
- Maximum Power dissipation PD: 150 W2
- Gate-to-source voltage VGS: Β±20 V2
- Peak diode recovery dv/dt: -5.5 V/ns2
- Total gate charge QG: 61 nC2
- On-state resistance RDS: 0.20 Ξ©2
- Operating temperature range: -55 to +175 ΛC2
Feature
- Advanced Process Technology
- Dynamic dv/dt Rating
- 175Β°C Operating Temperature
- Fast Switching
- P-Channel
- Fully Avalanche Rated
SpecificationΒ Β Β
- PackageΒ Β Β TO-220-3
- Transistor PolarityΒ Β Β P
- Maximum Drain Source VoltageΒ Β Β -100 V
- Maximum Continuous Drain CurrentΒ Β Β -23 A
- Maximum Gate Source VoltageΒ Β Β Β±20V
- Power DissipationΒ Β Β 140 W
- Number of Elements per ChipΒ Β Β 1
- Maximum Forward VoltageΒ Β Β -100VDC
- Output PowerΒ Β Β 140W
- Peak Non-Repetitive Surge CurrentΒ Β Β -76A
- Maximum Reverse CurrentΒ Β Β -25uA
- Channel ModeΒ Β Β P-Channel Enhancement
- Peak Reverse Recovery TimeΒ Β Β 67ns
- Channel TypeΒ Β Β P
- Repetitive Peak Reverse VoltageΒ Β Β -100VDC
- ConfigurationΒ Β Β Single
- Maximum Drain Source ResistanceΒ Β Β 0.117 Ohms@10V
- CategoryΒ Β Β Power MOSFET
- Maximum Forward CurrentΒ Β Β -23A
- Typical Fall TimeΒ Β Β 51ns
- Typical Gate Charge @ VgsΒ Β Β 97nC @10V
- Typical Input Capacitance @ VdsΒ Β Β 1300pF@25V
- Typical Rise TimeΒ Β Β 67ns
- Typical Turn-Off Delay TimeΒ Β Β 51ns
- Typical Turn-On Delay TimeΒ Β Β 15ns
- Minimum Operating TemperatureΒ Β Β -55Β°C
- Maximum Operating TemperatureΒ Β Β 175Β°C
- MountingΒ Β Β Through Hole
- PackagingΒ Β Β Bulk
- PinsΒ Β Β 3
- FamilyΒ Β Β IRF9540
- WidthΒ Β Β 4.69mm
- HeightΒ Β Β 8.77mm
- Product LengthΒ Β Β 10.54mm
- Product TypeΒ Β Β MOSFET
Order yourΒ IRF9540 P-Channel Power MOSFETΒ from Digilog.pk today and experience the power of advanced MOSFET technology.
