MPU6500 GY-6500 6DOF 6 Axis Accelerometer Gyro Sensor
Pickup available at Digilog Electronics
Usually ready in 2 hours
MPU6500 GY-6500 6DOF 6 Axis Accelerometer Gyro Sensor
The MPU6500 GY-6500 6DOF 6 Axis Accelerometer Gyro Sensor is a compact and versatile sensor module designed to provide precise motion sensing capabilities for various electronic applications. This module integrates both accelerometer and gyroscope sensors, offering a comprehensive 6-degree-of-freedom (6DOF) measurement solution in a single package.
Features:
- Typically includes programmable full-scale range (e.g., ±2g, ±4g, ±8g, ±16g).
- Offers high resolution for precise measurement of acceleration.
- Usually supports a wide range of angular rates (e.g., ±250°/s, ±500°/s, ±1000°/s, ±2000°/s).
- Measures angular velocity around three axes (X, Y, Z).
| Model Type: |
Accelerometer Sensor, Gyroscope Sensor |
|---|---|
| MPU |
6500 module (three-axis gyroscope + three-axis acceleration) |
| Chip |
MPU-6500 |
| Power Supply(V) |
3-5v (internal low voltage regulator) |
| Communication Mode |
Standard IIC / SPI communication protocol |
| Converter Type |
16bit AD converter, 16-bit data output |
| Gyroscope |
±250 500 1000 2000 °/ s |
| Acceleration (g) |
±2 ±4 ±8 ±16g |
| Pitch (mm): |
2.54mm |
| Module Size (LxWxH) mm |
15mm * 25mm |
| Shipping Weight | 0.002 kg |
| Shipping Dimensions | 8 × 6 × 1 cm |
Package Includes:
1 x MPU6500 GY-6500 6DOF 6 Axis Accelerometer Gyro Sensor
