UNI-T UTi740MS Smartphone Thermal Camera for iOS and Android
UNI-T UTi740MS is a professional smartphone thermal camera module for electrical, mechanical, HVAC and building inspection. IR Resolution 400×300; NETD ≤ 45mK; Temperature Range -20 °C (-4 °F) to 550 °C (1022 °F); Accuracy ±2 °C or ±2% (whichever greater). Genuine UNI-T supplied by Digilog.pk with manual and warranty.
Key Features
- IR Resolution: 400×300
- NETD: ≤ 45mK
- Temperature Range: -20 °C (-4 °F) to 550 °C (1022 °F)
- Accuracy: ±2 °C or ±2% (whichever greater)
- Field of View: 29° × 21.5°
- Spectral Response: 8 - 14µm
- Plug-in thermal module — turns your smartphone into a thermal camera
- Applications: electrical panels, motors, HVAC, building & water-leak inspection
Technical Specifications
| IR Resolution | 400×300 |
|---|---|
| NETD | ≤ 45mK |
| Temperature Range | -20 °C (-4 °F) to 550 °C (1022 °F) |
| Accuracy | ±2 °C or ±2% (whichever greater) |
| Field of View | 29° × 21.5° |
| Spectral Response | 8 - 14µm |
| Pixel Pitch | 12µm |
| Refresh Rate | 25 Hz |
| Spatial Resolution | 1.26mrad |
| Focus | Manual Focus |
| Super Resolution | Yes |
| Image Blending | Yes |
| Isotherm | Yes |
| Image Modes | Thermal, T-Mix fusion, PIP |
| Image Format | Radiometric JPEG |
| Video Recording | Yes |
What's in the Box
- UTi740MS smartphone thermal camera module
- USB cable
- English user manual
Downloads
Certifications: CE, RoHS | HS Code: 9027.50
