UNI-T UTi320V Thermal Imaging Camera – 320×240 IR, −20 to 350°C, ≤60 mK, 42.5°×32.5° FOV, ×2 Zoom, Industrial Thermal Camera
Pickup available at Digilog Electronics
Usually ready in 2 hours
UNI-T UTi320V Thermal Imaging Camera – 320×240 IR, −20 to 350°C, ≤60 mK, 42.5°×32.5° FOV, ×2 Zoom, Industrial Thermal Camera
The UNI-T UTi320V is an industrial thermal imaging camera that converts invisible infrared radiation into a visible thermal image for fault-finding in the dark and non-contact temperature analysis. It features a 320 × 240 infrared detector, a −20 to 350°C measurement range, high thermal sensitivity (≤60 mK) and a wide 42.5° × 32.5° field of view. Genuine UNI-T product supplied by Digilog.pk.
Key Features
- 320 × 240 infrared resolution
- Temperature range −20°C to 350°C (−4°F to 662°F)
- High thermal sensitivity NETD ≤60 mK
- Wide field of view 42.5° × 32.5°; 7 mm free-focus lens
- ×2 digital zoom; 50 Hz frame rate
Technical Specifications
| IR Resolution | 320 × 240 |
|---|---|
| Temperature Range | −20°C to 350°C (−4°F to 662°F) |
| Thermal Sensitivity (NETD) | ≤60 mK |
| Field of View | 42.5° × 32.5° |
| Frame Rate | 50 Hz |
| Digital Zoom | ×2 |
| Lens | 7 mm, free focus |
| Temperature Coefficient | ±0.1/°C or ±0.1% |
What's in the Box
- UTi320V thermal imaging camera
- Rechargeable battery
- Charger/cable
- English user manual
Downloads
Certifications: CE, RoHS | HS Code: 9027.50
