New
UNI-T UT725 Multifunction Process Calibrator – mA, V, Temperature (TC/RTD), Frequency, Resistance, Pulse Source & Measure, 20000 Count
Pickup available at Digilog Electronics
Usually ready in 2 hours
UNI-T UT725 Multifunction Process Calibrator – mA, V, Temperature (TC/RTD), Frequency, Resistance, Pulse Source & Measure, 20000 Count
UNI-T UT725 Multifunction Process Calibrator – mA, V, Temperature (TC/RTD), Frequency, Resistance, Pulse Source & Measure, 20000 Count
UNI-T UT725 — a all-in-one process calibrator combining temperature (thermocouple & RTD), loop current (mA), DC voltage, resistance, frequency and pulse source and measurement, with 24 V loop power, 20000-count display and 0.02% accuracy. Genuine UNI-T product supplied by Digilog.pk with warranty.
Key Features
- All-in-one — mA, V, temperature (TC/RTD), resistance, frequency and pulse in one tool
- Thermocouples R,S,K,E,J,T,N,B,L,U,XK,BP and RTDs Pt100–Pt1000/Cu
- Loop current 0–20 mA source/measure with 24 V loop power
- Frequency/pulse to 100 kHz; DC voltage to 50 V; resistance to 40 kΩ
- 20000-count display, up to 0.02% accuracy, step/ramp, USB, rechargeable
Technical Specifications
| DC voltage (V) (source) | 50mV/500mV/50V |
|---|---|
| DC current (mA) | 20mA |
| Loop current (mA) | 20mA |
| Resistance (Ω) (source) | 500Ω/5000Ω |
| Frequency (Hz) (source) | 100Hz/1kHz/10kHz/100kHz |
| Thermocouples (source) | R,S,K,E,J,T,N,B,L,U,XK,BP |
| RTDs (source) | Pt100/Pt200/Pt500/Pt1000/Cu10/Cu50/Cu100/Pt100-392/Pt100-JIS/Ni120 |
| Continuity test | √ |
| Pulses (Hz) (source) | 1~15kHz (1~100000 periods) |
| DC voltage (V) (measure) | 100mV/1000mV/10V |
| DC current (A) | 20mA/20mA(SIM) |
| Resistance (Ω) (measure) | 400Ω/4000Ω/40kΩ |
| Frequency (Hz) (measure) | 200Hz/2000Hz/20kHz/100kHz |
| Pulses (Hz) (measure) | 100Hz/1kHz/10kHz |
| Thermocouples (measure) | R,S,K,E,J,T,N,B,L,U,XK,BP |
| RTDs (measure) | Pt100-385/Pt100-392/Pt100-JIS/Pt200-385/P500-385/Pt1000-385/Cu10/Cu50/Cu100/Ni120 |
What's in the Box
- Process calibrator main unit
- Test leads
- USB cable
- Power adapter
- Temperature probe (UT714/UT725)
- English user manual
- Calibration certificate
Downloads
Certifications: CE, RoHS | HS Code: 9030.89
