UNI-T UT673PV Solar MPPT Power Meter – 5–800W, 12–60V, 0–35A, Manual/Auto MPPT Test, Solar-Panel Powered, PV Output Tester
Pickup available at Digilog Electronics
Usually ready in 2 hours
UNI-T UT673PV Solar MPPT Power Meter – 5–800W, 12–60V, 0–35A, Manual/Auto MPPT Test, Solar-Panel Powered, PV Output Tester
UNI-T UT673PV is a solar MPPT power meter that finds a PV panel's maximum-power point — measuring max power (5–800 W), voltage (12–60 V), current (0–35 A) plus open-circuit and short-circuit values. It needs no battery — the panel powers it. Genuine UNI-T supplied by Digilog.pk with manual and warranty.
Key Features
- Max-power measurement 5–800 W; voltage 12–60 V DC; current 0–35 A
- Open-circuit and short-circuit measurement; manual/auto MPPT test
- Large LCD (52×66 mm) with data hold
- No battery required — powered by the solar panel
- Reverse-polarity, over-voltage/current/power and over-temperature protection
- CAT 0 60V; CE, cETLus, RoHS
Technical Specifications
| Max Power | 5–800 W |
|---|---|
| Voltage (DC) | 12–60 V |
| Current (DC) | 0–35 A |
| Open/Short Circuit | measured |
| MPPT Test | Manual / Auto |
| Display | LCD 52×66 mm |
| Power | Solar-panel powered (no battery) |
| Category | CAT 0 60V |
What's in the Box
- UT673PV solar MPPT meter
- Test leads / connectors
- English user manual
- Gift box
Downloads
Certifications: CE, cETLus, RoHS | HS Code: 9030.39
