UNI-T UT673PV+ Solar MPPT Meter – 5–2200W, 10–150V, 0–20A, Bluetooth App, Data Storage, MC4 Test Lead, CAT 0 150V, PV Solar Panel Tester
UNI-T UT673PV+ — solar MPPT meter that tests solar panels for maximum power, voltage and current to find abnormalities. With a large screen, automatic measurement and a portable design, it improves efficiency for photovoltaic industry professionals and users. This plus model extends the range to 2200W / 150V / 20A and adds a Bluetooth app and data storage over the standard UT673PV. Genuine UNI-T product supplied by Digilog.pk with warranty.
Key Features
- Maximum power test (Pmax) 5 – 2200W
- Peak power voltage (Vmp) 10 – 150V; peak power current (Imp) 0 – 20A
- Open circuit voltage (Voc) 10 – 150V; short circuit current (Isc) 0 – 20A
- Bluetooth app and data storage; large screen with multiple result display
- Equipped with an MC4 test lead; CAT 0 150V
- Reverse polarity, overvoltage, overcurrent, over-temperature and overpower protection
Technical Specifications
| Pmax (maximum power) | 5～2200W, ±(1.0%＋10) |
|---|---|
| Vmp (peak power voltage) | 10～150V, ±(1.5%＋5) |
| Imp (peak power current) | 0～20A, ±(1.5%＋5) |
| Voc (open circuit voltage) | 10～150V, ±(1.5%＋5) |
| Isc (short circuit current) | 0～20A, ±(1.5%＋5) |
| Display | Large LCD (52 × 66 mm) |
| Manual MPPT test | Yes |
| Bluetooth app | Yes |
| Data storage | Yes |
| Data hold | Yes |
| Reverse polarity connect protection | Yes |
| Overvoltage protection | Yes |
| Overcurrent protection | Yes |
| Over temperature protection | Yes |
| Overpower protection | Yes |
| Category rating | CAT 0 150V |
| Product colour | Red + Black |
| Product size | 169 × 81 × 46 mm |
What's in the Box
- UT673PV+ solar MPPT meter
- MC4 test lead
- English user manual
Downloads
Certifications: CE, cETLus, RoHS | HS Code: 9030.39
