UNI-T UT658C USB Tester – Type-A & Type-C, 4~24 V, A:0.05~3 A / C:0.05~5 A, Capacity/Energy, QC 2.0/4.0
The UNI-T UT658C is a dual Type-A and Type-C USB tester for checking modern chargers, PD/QC power banks and USB-C cables — reads voltage, current, capacity and energy on either port.
It measures 4–24 V with up to 3 A on Type-A and 5 A on Type-C, logs mAh/Wh, tests cable resistance and data-line voltage, and detects QC 2.0/4.0 fast charging. Genuine UNI-T product supplied by Digilog.pk.
Key Features
- 🔌 USB Type-A & Type-C inline tester
- 📏 4~24 V; Type-A 0.05~3 A, Type-C 0.05~5 A
- 🔋 Capacity (mAh) & energy (Wh) logging; QC 2.0/4.0
- 🧵 Cable resistance (1~480 Ω) & D+/D- voltage
- 💾 10 record sets; up to 99 h timing
Technical Specifications
| Ports | USB Type-A + Type-C (in & out) |
|---|---|
| Protocol | QC 2.0 / 4.0 |
| Voltage | 4 ~ 24 VDC (0.01 V) |
| Current (Type-A) | 0.05 ~ 3 ADC |
| Current (Type-C) | 0.05 ~ 5 ADC |
| Capacity | 0 ~ 99999 mAh |
| Energy | 0 ~ 1000 Wh |
| Cable resistance | 1 ~ 480 Ω |
| Data storage | 10 sets |
| Max recording time | 99 h 59 min 59 s |
What's in the Box
- UT658C USB tester
- English user manual
Downloads
Certifications: CE | HS Code: 9030.39
