UNI-T UT620A Digital Micro Ohm Meter – 60000 Count, 10µΩ Resolution, 4-Wire Kelvin, Wire-Length, USB, Rechargeable Low-Resistance Ohmmeter
Pickup available at Digilog Electronics
Usually ready in 2 hours
UNI-T UT620A Digital Micro Ohm Meter – 60000 Count, 10µΩ Resolution, 4-Wire Kelvin, Wire-Length, USB, Rechargeable Low-Resistance Ohmmeter
UNI-T UT620A is a digital micro-ohm meter with 60000-count resolution down to 10 µΩ using a 4-wire Kelvin method — for measuring contact resistance, welds, windings, bus bars and low-resistance connections. Genuine UNI-T supplied by Digilog.pk with manual and warranty.
Key Features
- 60000-count display, resolution to 10 µΩ (60mΩ/10A – 6kΩ ranges)
- 4-wire Kelvin measurement for accurate low-resistance readings
- Wire-length measurement; high/low limit alarm
- 1000-record data storage and USB data transmission
- Manual range, backlight, relative mode, low-battery indication
- Rechargeable 7.4V 4000 mAh Li-ion; Kelvin clip leads and PC software
Technical Specifications
| Display Count | 60000 |
|---|---|
| Resolution | 10 µΩ |
| Ranges | 60mΩ/10A · 120mΩ/5A · 600mΩ/1A · 6Ω · 60Ω · 600Ω · 6kΩ |
| Basic Accuracy | ±(0.25%+25) |
| Method | 4-wire Kelvin |
| Storage | 1000 records |
| Interface | USB |
| Power | 7.4V 4000mAh Li-ion (rechargeable) |
| Weight | 1.5 kg |
What's in the Box
- UT620A micro ohm meter
- Kelvin clip test leads (red & black)
- Power cord
- Power adaptor
- USB cable
- PC software CD
- Carrying bag
- English user manual
Downloads
Certifications: CE, RoHS | HS Code: 9030.39
