UNI-T UT512E2.5kV 2.5kV Insulation Resistance Tester – 2.5kV Digital Megohmmeter, 250V/500V/1000V/2500V
Pickup available at Digilog Electronics
Usually ready in 2 hours
UNI-T UT512E2.5kV 2.5kV Insulation Resistance Tester – 2.5kV Digital Megohmmeter, 250V/500V/1000V/2500V
UNI-T UT512E2.5KV is a 2.5kV insulation resistance tester for electricians and maintenance engineers. Genuine UNI-T supplied by Digilog.pk with manual and warranty.
Key Features
- Test Voltages: 250V/500V/1000V/2500V
- Max Resistance Range: 500GΩ
- PI test: automatic display
- DAR test: automatic display
- Monitoring function: Monitor the voltage of the measured object and the discharge state after testing.
- Applications: electrical maintenance, wiring, panels and safety testing
Technical Specifications
| Test Voltages | 250V/500V/1000V/2500V |
|---|---|
| Max Resistance Range | 500GΩ |
| PI test | automatic display |
| DAR test | automatic display |
| Monitoring function | Monitor the voltage of the measured object and the discharge state after testing. |
| Timer testing | Record testing time automatically. Timing range: 0s～99m and 59s |
| Data transmission | Upload testing data to the computer via USB cable. |
| CAT rating | CAT Ⅳ 600V |
| Certificates | CE/UKCA |
| Power supply | 8 * LR14 Alkaline battery |
What's in the Box
- UT512E2.5KV 2.5kv insulation resistance tester
- Test leads
- English user manual
- Carrying case
Downloads
Certifications: CE, RoHS | HS Code: 9030.39
