UNI-T UDP6952B 600W Programmable DC Power Supply – Single Channel, 0–60V / 0–25A, 1 mV / 0.1 mA, RS232 / RS485 / USB / LAN
UNI-T UDP6952B is a high-performance single-channel programmable DC power supply — 600 W over 0–60 V / 0–25 A with 1 mV / 0.1 mA resolution and excellent regulation. Full connectivity (RS232 / RS485 / USB / LAN) makes it ideal for automated test and research. Genuine UNI-T product supplied by Digilog.pk with warranty.
Key Features
- Single channel, 600 W: 0–60 V / 0–25 A
- High resolution 1 mV / 0.1 mA for fine setting and readback
- Excellent regulation: ≤ 0.03% + 5 mV / ≤ 0.1% + 25 mA
- RS232, RS485, USB and LAN interfaces for full remote control
- Stable, precise high-power output for lab and industry
- Wide-range AC input 100–240 V, 47–63 Hz
Technical Specifications
| Channels | 1 (single output) |
|---|---|
| Output Voltage | 0 – 60 V |
| Output Current | 0 – 25 A |
| Output Power | 600 W |
| Resolution | 1 mV / 0.1 mA |
| Accuracy | ≤ 0.03% + 5 mV / ≤ 0.1% + 25 mA |
| Interfaces | RS232, RS485, USB, LAN |
| AC Input | 100–240 V, 47–63 Hz |
What's in the Box
- UDP6952B DC power supply
- AC power cord
- Output test leads
- English user manual
Certifications: CE, UKCA | HS Code: 8504.4090
