Nema17 Stepper Motor For 3d Printer And Cnc (NEW)

Nema17 Stepper Motor For 3d Printer And Cnc (NEW)

Regular price Rs 1,500
Regular price Sale price Rs 1,500
Sale Sold out
Shipping calculated at checkout.

SKU:B512KRT148

Advance Payment Only

NOTIFY ME WHEN IN STOCK

This 42BYGHW804  IM42HS60 NEMA17 Stepper Motor For 3D Printer is a High-torque stepper motor in size NEMA 17 (42 mm) with a 1.8° step angle (full step) with D-Shaft for easy and reliable connection with coupler. 42BYGHW804  Nema17 steppers are a great way to get things moving, especially when positioning and repeatability are a concern. This is a Bipolar motor.

Get42BYGHW804  IM42HS60 NEMA17 Stepper Motor For 3D Printer And CNC in low price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Multan, Quetta, Faisalabad, Khuzdar, Abbottabad, Taxila, Rahim Yar Khan, Mardan, Jamshoro, Sialkot, Nawabshah, Nowshera, Swabi, Kohat and all over Pakistan. Best Quality 42BYGHW804  IM42HS60 NEMA17 Stepper Motor For 3D Printer And CNC

Specifications:

  1. Step Angle: 1.8
  2. Holding Torque: 4.8kg.cm
  3. Rated Voltage:  3.6Volt
  4. Rated Current:  1.2A/Phase
  5. Form Factor:  NEMA 17
  6. Shaft Type D-Shaft
  7. Wire Connector  JST PH male connector.
  8. 2-Phase (4-Wires)
  9. Holding Torque: 48N.cm (4800g-cm)
  10. Resistance: 3.2Ω/phase
  11. Inductance: 5mH/phase
  12. Form factor: NEMA 17

Dimensions:

  • 42 x 42 x 47mm
  • Weight: 380g
  • Shaft Diameter: 5mm
  • Shaft Length: 18mm
  • 4 x M3 Holes for mounting base

Connections:

  1. A+ : Black
  2. A- : Green
  3. B+ : Red
  4. B- :Blue

Package Includes:

  • 1 x Nema17 Stepper Motor

Best online shopping website for 42BYGHW804 IM42HS60 NEMA17 Stepper Motor For 3D Printer And CNC at a cheap price in Lahore Islamabad Karachi Faislabad Multan Quetta Sukkur Peshawar Rawalpindi and all over Pakistan.
