Name: Espressif ESP32 Wroom 32D Development Board
Brand: China
SKU: B489,krt223 IMP50,Th25,A
Price: 1160.0 PKR
Availability: InStock

Home ESP32 & ESP8266 WiFi Modules

Espressif ESP32 Wroom 32D Development Board - angled to show the shielded module, micro-USB port, BOOT and reset buttons and labelled GPIO headers.

Espressif ESP32 Wroom 32D Development Board - a black PCB, a central metal module, a micro-USB port, and two tactile buttons labeled EN and Boot.

Espressif ESP32 Wroom 32D Development Board - a black rectangular circuit board with a micro-USB port, two push buttons, and a metal-shielded module.

Espressif ESP32 Wroom 32D Development Board - shown from the front, featuring a micro-USB port, two push buttons, and black header pins on a black board.

Espressif ESP32 Wroom 32D Development Board - a black rectangular circuit board with a metal module, pin headers, a micro-USB port, and a boot button.

Espressif ESP32 Wroom 32D Development Board - shown from the bottom, featuring a black PCB with labeled pins and a micro-USB port next to a US quarter.

Espressif ESP32 Wroom 32D Development Board - shown on an Arduino IDE screen displaying code and a serial monitor outputting the text www.digilog.pk.

-19%

Espressif ESP32 Wroom 32D Development Board

Rs 1,439

Rs 1,160

SKU: B489,krt223 IMP50,Th25,A

Pickup available at Digilog Electronics

Usually ready in 2 hours

Espressif ESP32 Wroom 32D Development Board

Rs 1,439

Rs 1,160

Jump right into what matters; Start prototyping with Espressif flagship SoC, ESP32. ESP32-DevKitC is a low-footprint, breadboard-friendly, minimum system development board which is powered by the ESP32-WROOM-32D module.

Board Selection Guide:

Testing Code:

//===========================

void setup() {

// initialize serial communication at 9600 bits per second:

Serial.begin(9600);

}

// the loop routine runs over and over again forever:

void loop() {

Serial.println("www.digilog.pk");

delay(500); // delay in between reads for stability

}

//============================

Features:

Amazon-Qualified Device
ESP32-DevKitC is an AWS-qualified development board. In addition to Espressif’s own ESP-IDF SDK, you can use Amazon FreeRTOS on ESP32-DevKitC. Amazon FreeRTOS provides out-of-the-box connectivity with AWS IoT, AWS Greengrass, and other AWS services.
New and Powerful
Built around ESP32-WROOM-32, this minimum system development board achieves optimal performance with its rich peripheral set, Wi-Fi and Bluetooth connectivity offered by our flagship SoC, ESP32. The limit is your imagination!
Rapid Prototyping
Get right into application design and development without worrying about RF performance and antenna design. ESP32-DevKitC has your basic system requirements already covered. Just plug in the USB cable and you’re good to go!
Flexible and Feature-Rich
ESP32-DevKitC contains the entire basic-support circuitry for ESP32-WROOM-32, including a USB-UART bridge, reset- and boot-mode buttons, an LDO regulator and a micro-USB connector. Every important GPIO is available to the developer.
Breadboard-Friendly
The ESP32-DevKitC pinout is optimized to enable prototyping on a breadboard. The on-board LDO output is led out for powering up additional off-board electronics. Peripheral outputs are grouped together for hassle-free prototyping.

ESP32 DoIT Development Board:

The development board breaks out all the module’s pins to 2.54 mm headers and provides a CP2102 USB-TTL serial adapter, programming and reset buttons, and a power regulator to supply the ESP32 with a stable 3.3 V. Espressif doubled-down on the CPU resources for the ESP32 with a dual-core, running at 160MHz and tons more pins and peripherals. Now supported by Arduino IDE!!

ESP32 is highly-integrated with in-built antenna switches, RF balun, power amplifier, low-noise receive amplifier, filters, and power management modules. ESP32 adds priceless functionality and versatility to your applications with minimal Printed Circuit Board (PCB) area requirements.
Buy Espressif ESP32 WROOM 32D Development Board at Pakistan's Best Online Shopping Store at a low price. Wide range of ESP 32. We deliver in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan and all over Pakistan

ESP32 DoIT Development BoardcFeatures:

240 MHz dual-core Tensilica LX6 microcontroller with 600 DMIPS
Integrated 520 KB SRAM
Integrated 802.11BGN HT40 Wi-Fi transceiver, baseband, stack, and LWIP
Integrated dual-mode Bluetooth (classic and BLE)
4 MByte flash
-40°C to +125°C operating temperature
On-board PCB antenna / IPEX connector for external antenna

Sensors:

Ultra-low noise analog amplifier
Hall sensor
10x capacitive touch interface
32 kHz crystal oscillator

GPIO:

3 x UARTs, including hardware flow control
3 x SPI
2 x I2S
12 x ADC input channels
2 x DAC
2 x I2C
PWM/timer input/output available on every GPIO pin
OpenOCD debug interface with 32 kB TRAX buffer
SDIO master/slave 50 MHz
Supports external SPI flash up to 16 MB
SD-card interface support

Security:

WEP, WPA/WPA2 PSK/Enterprise
Hardware-accelerated encryption: AES / SHA2 / Elliptical Curve Cryptography / RSA-4096

Performance:

Supports sniffer, station, softAP and Wi-Fi direct modes
Max data rate of 150 Mbps@11n HT40, 72 Mbps@11n HT20, 54 Mbps@11g, and 11 Mbps@11b
Maximum transmit power of 19.5 dBm@11b, 16.5 dBm@11g, 15.5 dBm@11n
Minimum receiver sensitivity of -98 dBm
135 Mbps UDP sustained throughput
2.5 μA deep sleep current

Data Sheet:
