ESP32 ESP-wroom-32

Rs 910

The ESP8266 started a small revolution by bringing WiFi to a small and cheap package that also had enough processing power and enough pins to get small things done. Now get ready to take your bite-sized WiFi capabilities to the next level with the ESP32 Development Board!ESP32-WROOM-32 is SMD module which you can integrate to your own PCB design. Espressif has taken care of all certifications and regulations so you can use it as is without certification hassles.

Specifications:

CPU and Memory
Xtensa� Dual-Core 32-bit LX6 microprocessors, up to 600 DMIPS
448 KByte ROM
520 KByte SRAM
16 KByte SRAM in RTC
QSPI Flash/SRAM, up to 4 x 16 MBytes
Power supply: 2.2 V to 3.6 V

Clocks and Timers

Internal 8 MHz oscillators with calibration
Internal RC oscillator with calibration
External 2 MHz to 40 MHz crystal oscillator
External 32 kHz crystal oscillator for RTC with calibration
Two timer groups, including 2 x 64-bit timers and 1 x main watchdog in each group
RTC timer with sub-second accuracy
RTC watchdog
