ZB2L3 HW-586 Battery Capacity Tester: Precise and Safe

Enhance your battery testing with our reliable ZB2L3 HW-586 Battery Capacity Tester. This external load discharge module offers accurate measurements, thanks to its resistive load and specially designed DC bias. Prevent overheating by mounting the included 50W aluminum resistor on a metal plate before use.

Key Features:

• Accurate battery capacity measurement
• Resistive load for efficient testing
• DC bias for improved accuracy
• Safe operation
• Easy-to-use interface

HW-586 Battery Capacity Tester: Accurate and Versatile

The HW-586 Battery Capacity Tester is an essential tool for anyone who needs to accurately measure battery capacity. This external load discharge module offers a range of features for comprehensive testing:

• Wide Measurement Range: Supports batteries with discharge voltage from 1.00V to 15.00V and capacities up to 9999Ah.


• Precise Readings: Measures voltage with a maximum error of 1% and current with a maximum error of 1.5%.
• Automated Testing: Automatically sets termination voltage based on battery full charge voltage or allows manual adjustment.
• Multiple Display Modes: Rotates between discharge capacity (Ah), current discharge current (A), and battery voltage (V) for real-time monitoring.
• Safety Features: Includes error codes for overcurrent and under voltage conditions.

Easy to Use:

1. Connect the battery and load securely.
2. Power on the tester with a micro USB power supply (not laptop/desktop USB).
3. Choose automatic or manual termination voltage setting.
4. Start the test and monitor data display.

Safety Notice:

• Use the included 50W aluminum resistor mounted on a metal plate to prevent overheating during discharge.
• Refer to the user manual for detailed instructions and troubleshooting.

Package Includes:

• 1 x HW-586 Battery Capacity Tester
• 2 x Resistor
• 4 x Screw with Standoff

Order your HW-586 Battery Capacity Tester today and ensure reliable battery performance!
