UNI-T UT18B Two-Pole Voltage & Continuity Tester – AC/DC 690V, Three-Phase Rotation, RCD Trigger, Polarity Detection, Continuity, CAT IV 600V IP65 with LED Indication
Pickup available at Digilog Electronics
Usually ready in 2 hours
UNI-T UT18B Two-Pole Voltage & Continuity Tester – AC/DC 690V, Three-Phase Rotation, RCD Trigger, Polarity Detection, Continuity, CAT IV 600V IP65 with LED Indication
UNI-T UT18B — Professional two-pole voltage & continuity tester with LED indication, AC/DC up to 690V, RCD test and IP65 rugged build. Genuine UNI-T product supplied by Digilog.pk with user manual and warranty.
Key Features
- Two-pole AC/DC voltage tester up to 690 V (LED indication)
- Three-phase rotation test (57–400 V AC)
- RCD trip test (230 V / 50–400 Hz)
- Polarity detection & continuity test
- Self-inspection, auto standby, work light, low-battery indication
- CAT IV 600V safety, IP65 dust & water resistant
Technical Specifications
| Type | Two-pole voltage & continuity tester (LED) |
|---|---|
| Voltage Ranges | 6 / 12 / 24 / 50 / 120 / 230 / 400 / 690 V AC/DC |
| Phase Rotation | 57–400 V AC (3-phase) |
| RCD Test | 230 V / 50–400 Hz |
| Continuity | Audible / visual |
| Safety Rating | CAT IV 600V |
| IP Rating | IP65 |
| Standby Current | < 10 µA (auto standby) |
| Power | 2 × 1.5 V AAA (R03) |
| Certifications | CE, UKCA, cETLus |
Video Review
What's in the Box
- UT18B two-pole tester
- 2 × 1.5 V AAA batteries
- English user manual
Downloads
Certifications: CE, UKCA, cETLus | HS Code: 9030.3900
