Description
The MDT10F684 is an efficient 8-bit microcontroller crafted by MDT (Micon Design Technology Corporation), housed in a compact SOP-14 package. With 2 K × 14 Flash ROM, 128 × 8 EEPROM, and 64 bytes of RAM, it offers flexible code storage and reliable performance for embedded applications. Running at frequencies up to 20 MHz and operating across temperatures from -40 °C to +85 °C, it’s ideal for industrial control, consumer electronics, and automation solutions.
🧠 Built-in Features
-
WDT (Watchdog Timer), Power-On Reset, Power-Edge Detector
-
Flexible oscillator support: LF/XT/HF/RC internal (4 MHz)
-
ADC: 8-channel 10-bit analog input
-
Comparator: Single-channel
-
Timer/CCP: 2× timers including PWM support
Designed for robustness, low-power operation (<1 µA sleep) and easy integration, the MDT10F684 is perfect for IoT, sensor interfaces, and smart devices.
📋 Technical Specifications Table
| Specification | Details |
|---|---|
| Manufacturer | MDT (Micon Design Technology Corp.) |
| Model | MDT10F684 |
| Package | SOP-14 |
| Flash ROM | 2 K × 14 bits |
| EEPROM | 128 × 8 bits |
| RAM | 64 bytes |
| Operating Voltage | 2.3 V – 5.5 V |
| Max Clock Frequency | 20 MHz |
| I/O Pins | 11 + 1 input-only PA3 |
| ADC Channels | 8 (10-bit resolution) |
| Comparators | 1 channel |
| Timers / PWM | 2 timers (1 CCP for PWM) |
| Power Features | WDT / POR / PED |
| Low Power Sleep Current | < 1 µA @ 5 V |
| Operating Temperature | -40 °C to +85 °C |
| Certifications | Lead-free / RoHS compliant |
📦 Package Includes
-
1 × MDT10F684 8-bit Microcontroller – SOP-14 Package
