CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2db - two small, cylindrical silver-coloured microphone capsules from different angles.

CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2db

Sale price Rs 30
SKU: B167,IMP500,Th50,KRT,A
Log in to use Wishlist
Add to Compare

Frequently Bought Together

Customers building this project usually buy these together.

CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2db - two small, cylindrical silver-coloured microphone capsules from different angles.
+
LM386 IC Audio Power Amplifier - an 8-pin black integrated circuit chip with silver metal leads, shown from an angled perspective against a white background.
+
CD4017 IC - a black 16-pin dual in-line package electronic component with white text markings on its top surface, shown from an angled perspective.
+
Capacitor 50V 0.47uF - a small black cylindrical electrolytic capacitor with two long metal wire leads extending from the bottom.
Capacitor 50V 0.47uF - a small black cylindrical electrolytic capacitor with two long metal wire leads extending from the bottom.
This item: CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2db -
Sale price Rs 30
LM386 IC Audio Power Amplifier - an 8-pin black integrated circuit chip with silver metal leads, shown from an angled perspective against a white background.
LM386 IC Audio Power Amplifier -
Sale price Rs 30
CD4017 IC - a black 16-pin dual in-line package electronic component with white text markings on its top surface, shown from an angled perspective.
CD4017 IC -
Sale price Rs 100
Capacitor 50V 0.47uF - a small black cylindrical electrolytic capacitor with two long metal wire leads extending from the bottom.
Capacitor 50V 0.47uF -
Sale price Rs 10
Price for all:
Sale total price Rs 170

Pickup available at Digilog Electronics

Usually ready in 2 hours

CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2db - two small, cylindrical silver-coloured microphone capsules from different angles.

CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2db

  • Digilog Electronics

    Pickup available, usually ready in 2 hours

    🏢 Digilog Electronics 13th the RegalStreet,
    Back side of KFC, Near Abubakar Masjid Mall Road
    Lahore
    Pakistan

    +923124002221

    Check this on google map
CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2db - two small, cylindrical silver-coloured microphone capsules from different angles.
CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2db
Sale priceRs 30

CZN-15E Omnidirectional Electret Condenser Microphone -62+/-2dB, also Electric condender microphone. Small electret microphone. Useful in acoustic and audio applications.

Specifications:

  1. Sensitivity: -62±2dB (0dB=1V/pa,1KHz)
  2. Impedance: Low impedance
  3. Directivity: Omnidirectional
  4. Frequency: 20-16,000Hz
  5. Voltage range: 1.5V-10V
  6. Standard operation voltage:4.5V
  7. Current consumption: Max.0.5mA
  8. Sensitivity reduction: Within -3dB at 3V
  9. S/N ratio: More than 60dB
