BC557 PNP Transistor – High-Quality General Purpose Transistor in Pakistan

The BC557 PNP Transistor is a versatile, general-purpose transistor widely used in switching and amplification applications by wide range of users mostly students. With its low noise and high performance, it is ideal for audio frequency circuits, signal processing, and general electronics projects. Its compact TO-92 package makes it easy to integrate into your designs.

Available now at Digilog.pk, this high-quality transistor can be shipped to cities across Pakistan, including Lahore, Karachi, Peshawar, Quetta, and Multan.

Find More Related Products:

• BC547 NPN Transistor
• 2N2222 NPN Transistor
• 4.7kΩ Resistor for Signal Processing

For detailed transistor characteristics, visit All About Circuits.

Key Features

• Type: PNP Bipolar Junction Transistor
• Voltage: Collector-Emitter Voltage (Vce) = 45V
• Current: Maximum Collector Current (Ic) = 100mA
• Power: Dissipation up to 500mW
• Applications: Ideal for low-noise amplification, switching, and signal processing circuits

Internal Linking Headline: Enhance Your Circuit Design

• BC547 NPN Transistor for Complementary Pairing
• Mini Breadboard for Easy Prototyping
• Variable Resistors for Precise Calibration

External Linking Headline: Deep Dive into Transistor Basics

• Understanding PNP and NPN Transistors
• Transistor Circuit Design Guide

FAQs

1. What is the primary application of the BC557 PNP transistor?
The BC557 is primarily used for amplification and low-power switching in audio and signal processing circuits.

2. How does it differ from the BC547 transistor?
The BC557 is a PNP transistor, while the BC547 is an NPN transistor. They are complementary to each other and can be used together in push-pull amplifier circuits.

3. What is the recommended operating voltage?
The BC557 can handle a maximum Collector-Emitter Voltage (VCE ) of 45V. For optimal performance, operate it well within this limit..

4. Can it be used for high-power circuits?
No, the BC557 is designed for low-power circuits with a maximum collector current of 100mA.

5. What are the storage requirements?
Store the transistor in a dry and static-free environment to prevent damage to its sensitive electronic properties.
