74ls08 74ahs08 Sn74ls08n Ls08n 7408 Quad 2-input And Gate

74HC08  Quad 2-input AND gate

Features & Specifications

• Four Independent AND Gates
• Standard Pin Configuration
• Fast Switching Times
• Operating Temperature up to 70oC
• High-Speed CMOS Type
•
• Type: DIP
• Voltage Rating: 2.0 to 6.0V
• Temperature Rating: 0 to 70Deg C
• Number of: 14 Pins
• Mounting: DIP

General Description

The MM74HC08 AND gates utilize advanced silicon-gate CMOS technology to achieve operating speeds similar to LS-TTL gates with the low power consumption of standard CMOS integrated circuits. The HC08 has buffered outputs, providing high noise immunity and the ability to drive 10 LS-TTL loads. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and ground.
