Ca 1 Digit 7 Segment 0.7 Inch Led Common Anode Display

1 Digit 7 Segment 0.7 Inch LED Common Anode Display is ideally suited to adding a display to your project. 0.7 Inch LED Common Anode Display is compatible with prototyping boards such as the MB-102 which feature standard sockets with a pin pitch of 2.54mm. This module lets you display your information in a bold and bright way, taking your project to new levels of display, writing all manners of numbers and words with numbers from 0-9, A-F, and –.

Features of 1 Digit 7 Segment 0.7 Inch LED Common Anode Display:

• 14.20mm (0.56”)Single-digit numeric display series.
• Standard brightness.
• Low current operation.
• Excellent character appearance.
• Easy mounting on P.C.boards or sockets
• Used widely in home appliances, instrument, car accessory, etc.

Specifications of 1 Digit 7 Segment 0.7 Inch LED Common Anode Display:

1. Digit height: is 0.7"  Overall height is 1"
2. Number of pins: 10 pins, which 2 of them are common anode pins.
3. Display type: single 7-segment
4. Wavelenght: 700nm
5. Luminous intensity: 5mcd
6. Character height: 14.2mm
7. Polarity: CA
8. Forward Voltage Vf: 2.2V
9. Forward current IF: 30mA
10. Reverse voltage Vr: 5V
11. Power Pd: 100mW
12. Mounting: THT

Package Includes:

1x 1 Digit 7 Segment 0.7 Inch LED Common Anode Display
