Dual Channel Amplifier Module Stereo has a higher overload capacity than the analogue amplifier. Although it won't cause crossover distortion, This is an audio power amplifier board that strengthens low-power, inaudible electronic audio signals. Such as the signal from radio receiver or electric guitar pickup to a level that is strong enough for driving loudspeakers or headphones. Power amplifiers make the signal audible to listeners.
This audio amp board is the final electronic stage in a typical audio playback chain before the signal is sent to the loudspeakers and speaker enclosures.
Features Of Digital Auto Dual Channel Amplifier Module Stereo AMP 12V-24V TDA3116:
- XH-M190 2*100W digital amplifier board 12V-24V wide voltage TPA3116 dual channel amplifier board.
- Using a wide DC voltage.
- Digital IC high resolution.
- High efficiency and low heat.
- 100W * 2 superpower.
- Proposed power supply DC 12-24V 100 or more switching power supply. This board is a finished board, a received can also be used.
- Using two new imports TPA3116 amplification chip, combined with nano-technology, in the field of digital power amplifier ahead.
- Clear sound, strong amplification function, high efficiency, also high-frequency response density.
Specifications Of High-Power 2.0 Channel Mono Audio Amplifier Board 12-24V 100Wx2:
- Chip: TPA3116
- input voltage: DC12-24V
- Output Power: 2*100W
- Input resistance: 51K*2
- Output matching: 4-8 ohm
- Frequency Range: 14-100Kz
- SNR: 100db
- Output Track: 2(left/right channel)
- Product size: approx. 105*65*23mm/4.13*2.55*0.9”
- Net weight: approx. 85g
Package Includes:
- 1 x Digital Amplifier Board
- 4 x Screws
