Wx110(010) 5k 1w Potentiometer

SKU: B521
Rs 200
Rs 200
Rs 0
Sold out
Quantity must be 1 or more

5K 1W Potentiometer:

  1. Resistance Value (5K): The "5K" in the description indicates the resistance value of the potentiometer. In this case, it's 5,000 ohms (or 5 kilohms). This means that when you use this potentiometer in a circuit, it can provide a variable resistance ranging from zero ohms to 5,000 ohms by turning its knob or shaft. It allows you to control the flow of electric current in a circuit.

  2. Power Rating (1W): The "1W" represents the power rating of the potentiometer, which is 1 watt. This rating specifies the maximum amount of electrical power that the potentiometer can safely dissipate as heat without getting damaged. In this case, it can handle up to 1 watt of power, making it suitable for circuits where higher power dissipation might occur.

  3. Potentiometer Type: Potentiometers come in various types, including rotary potentiometers (where you turn a knob) and slide potentiometers (where you slide a slider). You would need to check the specific type of potentiometer this description refers to.

  4. Applications: Potentiometers are used in a wide range of applications, including audio volume controls, voltage regulators, tuning circuits, and other applications where precise control of resistance or voltage is required.

  5. Construction: The physical construction of a 5K 1W potentiometer typically involves a resistive element (usually a long, coiled wire or a conductive material) connected to three terminals: the input terminal, the wiper terminal (connected to the moving part or knob), and the output terminal. By adjusting the position of the wiper relative to the resistive element, you can change the resistance value between the input and output terminals.

  6. Mounting: Potentiometers can be panel-mounted or PCB-mounted, depending on the application and design requirements. Panel-mounted potentiometers often have a threaded shaft that allows them to be secured to a control panel or enclosure.

  7. Tolerance: Potentiometers have a tolerance rating that indicates how closely the actual resistance matches the specified resistance value. Common tolerances for potentiometers include 10%, 5%, and 1%, with 1% being the most precise.
